| 缸套直径 | in | 61/2 | 61/4 | 6 | 5/1/2 | 5 | 4 1/2 | 4 |
| 排出压力 | MPa | 14.6 | 15.8 | 17.2 | 20.4 | 24.7 | 30.5 | 34.5 |
| psi | 2118 | 2290 | 2495 | 2915 | 3582 | 4424 | 5000 | |
| 冲次 SPM | 输入功率 kW(HP) | 排量 L/s(GPM) | ||||||
| 160 | 636 (853) | 39.21 (621.4) | 36.26 (574.7) | 33.41 (529.5) | 28.07 (444.9) | 23.20 (367.7) | 18.79 (297.8) | 14.85 (235.3) |
| *150 | *597 (800) | 36.76 (582.6) | 34 (538.9) | 31.32 (496.4) | 26.32 (417.1) | 21.75 (344.7) | 17.62 (279.2) | 13.92 (220.6) |
| 140 | 557.2 (746.7) | 34.3 (543.6) | 31.73 (502.9) | 29.23 (463.3) | 24.57 (389.4) | 20.3 (321.7) | 16.45 (260.7) | 12.99 (205.8) |
| 130 | 517.4 (693.3) | 31.85 (504.8) | 29.47 (467.1) | 27.14 (430.1) | 22.81 (361.5) | 18.85 (298.7) | 15.27 (242.0) | 12.06 (191.1) |
| 120 | 477.6 (640) | 29.4 (465.9) | 27.2 (431.1) | 25.06 (397.2) | 21.06 (333.8) | 17.4 (275.7) | 14.1 (223.4) | 11.14 (176.5) |
| 110 | 437.8 (587.7) | 26.95 (427.1) | 24.93 (395.1) | 22.97 (364.0) | 19.3 (305.9) | 15.95 (252.8) | 12.92 (204.7) | 10.21 (161.8) |
| 1 | 3.98 (5.33) | 0.245 (3.88) | 0.227 (3.59) | 0.209 (3.31) | 0.175 (2.77) | 0.145 (2.29) | 0.117 (1.85) | 0.093 (1.47) |
